在前面的小结，我们使用了 direct exchange 代替盲目广播的 fanout exchagne 使得接受者能够选择需要接收的日志消息。但 direct exchange 还是存在局限性——它无法根据多标准路由。

日志系统中，我们可能不止需要根据日志级别订阅消息，同时也需要基于 ”日志发送来源“ 来过滤。你可能从 syslog unix tool 得知可以通过日志的 严重级别 severity (info/warn/crit…) 和 来源设备 facility (auth/cron/kern…) 来路由日志。

这会基于我们更多的灵活性 —— 我们也许只想监听来自 ‘cron’ 的 critical errors 和 所有来自 ‘kern’ 的日志。

Topic exchange

发送到 topic exchange 的消息能跟随一个任意的 routing_key —— 它必须是由许多点分隔的单词列表，单词可以是任意的词，但通常是指定了消息的某些特性。

如下是几个合法的 routing key：”stock.usd.nyse”, “nyse.vmw”, “quick.orange.rabbit”。

你可以在 routing key 中定义任意数量的单词，但上限为 255 字节（bytes）。

binding key 也必须是同样的格式，topic exchange 背后的逻辑和 direct 是类似的 —— 发送到指定 routing key 的消息将被分发到所有绑定了相匹配的 binding key 的队列。 但是 binding keys 有两个重要特殊例子：

  • *（star）星号能完全代替 1 个单词
  • #（hash） 井号能代替 0 个或多个单词。

如以下例子：

python-five

在这个例子中，我们将发送的所有消息都是描述动物的。发送的消息将跟随由3个单词（2个分隔号）组成的 routing key。第一个单词描述速度（speed），第二个颜色（colour），第三个物种（species）： "<speed>.<colour>.<species>"

接着创建 binding： Q1 和 *.orange.* 绑定，Q2 和 *.*.rabbit 以及 lazy.# 绑定。

这些绑定总结为：

  • Q1 对所有 orange 的动物感兴趣
  • Q2 监听所有关于 rabbit 和 lazy 的动物

例子：

“quick.orange.rabbit” 和 “lazy.orange.elephant” 的消息将被分发给两个队列，

“quick.orange.fox” 将只被分发个第一个队列，”lazy.brown.fox” 将只被分发给第二个队列，

“lazy.pink.rabbit“ 将只分发给第二个队列一次，即使它匹配了两个 binding。”quick.brown.fox” 不匹配任何 binding，消息将被丢弃。

如果我们不按约定而发送1个单词或者4个单词的消息，如：”orange” or “quick.orange.male.rabbit” ， 这些消息不匹配任何一个 binding，将被丢弃。但是”lazy.orange.male.rabbit” 虽然有四个单词，但是它将匹配最后一个 binding lazy.# 并分发给第二个队列。

Topic exchange

Topic exchange 非常强大，它能表现得像其他的 exchange 一样。

当队列绑定了 binding key “#”（hash） —— 它将收到所有的消息，不管 routing key 是怎样的 —— 这表现得像 fanout exchange。

当这些特殊字符 “”（star）和 “#”（hash）不在 binding 中使用，topic exchange 将表现得像 *direct exchange

合并代码

我们将在日志系统中使用 topic exchange ，假定日志的 routing key 有两个单词：<facility>.<severity>

EmitLogTopic.java

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
public class EmitLogTopic {
  private static final String EXCHANGE_NAME = "topic_logs";
  public static void main(String[] argv) {
    Connection connection = null;
    Channel channel = null;
    try {
      ConnectionFactory factory = new ConnectionFactory();
      factory.setHost("localhost");
      connection = factory.newConnection();
      channel = connection.createChannel();
      channel.exchangeDeclare(EXCHANGE_NAME, BuiltinExchangeType.TOPIC);

      /**
       *  both severity (info/warn/critical...) and facility (auth/cron/kern...).
       */
      String routingKey = "auth.info";
      String message = "A critical kernel error";
      channel.basicPublish(EXCHANGE_NAME, routingKey, null, message.getBytes("UTF-8"));
      System.out.println(" [x] Sent '" + routingKey + "':'" + message + "'");
    }
    catch  (Exception e) {
      e.printStackTrace();
    }
    finally {
      if (connection != null) {
        try {
          connection.close();
        }
        catch (Exception ignore) {}
      }
    }
  }
}

ReceiveLogsTopic.java

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
package org.demo.rabbitMQDemo.logQueues.topic;
import com.rabbitmq.client.*;
import java.io.IOException;
public class ReceiveLogsTopic {
  private static final String EXCHANGE_NAME = "topic_logs";
  public static void main(String[] argv) throws Exception {
    ConnectionFactory factory = new ConnectionFactory();
    factory.setHost("localhost");
    Connection connection = factory.newConnection();
    Channel channel = connection.createChannel();
    channel.exchangeDeclare(EXCHANGE_NAME, BuiltinExchangeType.TOPIC);
    String queueName = channel.queueDeclare().getQueue();
    /**
      * 所有来源、所有等级的日志都需要打印到屏幕上
      */
    String[] topics = new String[]{"#"};
    for (String bindingKey : topics) {
      channel.queueBind(queueName, EXCHANGE_NAME, bindingKey);
    }
    System.out.println(" [*] Waiting for messages. To exit press CTRL+C");
    Consumer consumer = new DefaultConsumer(channel) {
      @Override
      public void handleDelivery(String consumerTag, Envelope envelope,
                                 AMQP.BasicProperties properties, byte[] body) throws IOException {
        String message = new String(body, "UTF-8");
        System.out.println(" [x] Received '" + envelope.getRoutingKey() + "':'" + message + "'");
      }
    };
    channel.basicConsume(queueName, true, consumer);
  }
}

ReceiveLogsTopicToDisk.java

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
package org.demo.rabbitMQDemo.logQueues.topic;
import java.io.FileNotFoundException;
import java.io.FileOutputStream;
import java.io.IOException;
import com.rabbitmq.client.AMQP;
import com.rabbitmq.client.BuiltinExchangeType;
import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;
import com.rabbitmq.client.Consumer;
import com.rabbitmq.client.DefaultConsumer;
import com.rabbitmq.client.Envelope;
public class ReceiveLogsTopicToDisk {
  private static final String EXCHANGE_NAME = "topic_logs";
  public static void main(String[] argv) throws Exception {
    ConnectionFactory factory = new ConnectionFactory();
    factory.setHost("localhost");
    Connection connection = factory.newConnection();
    Channel channel = connection.createChannel();
    channel.exchangeDeclare(EXCHANGE_NAME, BuiltinExchangeType.TOPIC);
    String queueName = channel.queueDeclare().getQueue();
    /**
     * both severity (info/warn/critical...) and facility (auth/cron/kern...).
     * 所有 from kern and critical severity 的日志会保存到日志文件中
     */
    String[] topics = new String[]{"kern.*","*.critical"};
    for (String bindingKey : topics) {
      channel.queueBind(queueName, EXCHANGE_NAME, bindingKey);
    }
    System.out.println(" [*] Waiting for messages. To exit press CTRL+C");
    Consumer consumer = new DefaultConsumer(channel) {
      @Override
      public void handleDelivery(String consumerTag, Envelope envelope,
                                 AMQP.BasicProperties properties, byte[] body) throws IOException {
        String message = new String(body, "UTF-8");
        message = " [x] Received '" + envelope.getRoutingKey() + "':'" + message + "'" + "\n";
        FileOutputStream file = null;
        try{
        	file = new FileOutputStream("./topic.log",true);
        	file.write(message.getBytes("UTF-8"));
        }catch(FileNotFoundException e){
        	e.printStackTrace();
        }finally{
        	file.close();
        }

      }
    };
    channel.basicConsume(queueName, true, consumer);
  }
}
1
2
3
4
5
6
7
8
9
10
11
# EmitLogTopic
 [x] Sent 'auth.info':'A critical kernel error'
 [x] Sent 'auth.warn':'A critical kernel error'
 [x] Sent 'auth.critical':'A critical kernel error'
 [x] Sent 'cron.info':'A critical kernel error'
 [x] Sent 'cron.warn':'A critical kernel error'
 [x] Sent 'cron.critical':'A critical kernel error'
 [x] Sent 'kern.info':'A critical kernel error'
 [x] Sent 'kern.warn':'A critical kernel error'
 [x] Sent 'kern.critical':'A critical kernel error'
1
2
3
4
5
6
7
8
9
10
11
12
13
# ReceiveLogsTopic
# see in console
 [*] Waiting for messages. To exit press CTRL+C
 [x] Received 'auth.info':'A critical kernel error'
 [x] Received 'auth.warn':'A critical kernel error'
 [x] Received 'auth.critical':'A critical kernel error'
 [x] Received 'cron.info':'A critical kernel error'
 [x] Received 'cron.warn':'A critical kernel error'
 [x] Received 'cron.critical':'A critical kernel error'
 [x] Received 'kern.info':'A critical kernel error'
 [x] Received 'kern.warn':'A critical kernel error'
 [x] Received 'kern.critical':'A critical kernel error'
1
2
3
4
5
6
7
8
# ReceiveLogsTopicToDisk
# see in file "topic.log"
 [x] Received 'auth.critical':'A critical kernel error'
 [x] Received 'cron.critical':'A critical kernel error'
 [x] Received 'kern.info':'A critical kernel error'
 [x] Received 'kern.warn':'A critical kernel error'
 [x] Received 'kern.critical':'A critical kernel error'

可以看出，屏幕上打印出来所有发送出去的日志消息，而日志文件只记录了等级为 “critical” 和所有来自 “kern” 的日志。
